Ariens Edge 52 - Engine Controls

EN - 10
See Figure 3 for all controls and features
locations.
IGNITION KEY
See Figure 4.
Controls power to the engine. The key cannot
be removed when in run position.
CHOKE CONTROL KNOB /
LEVER
Model 915285
See Figure 5.
Controls airflow to the engine.
Models 915281, 915283
See Figure 6.
THROTTLE CONTROL LEVER
See Figure 7.
Controls engine speed.
POWER-TAKE-OFF (PTO) KNOB
See Figure 8.
Controls power to mower blades. The engine
will not start with the PTO knob in the on
position.
WARNING: AVOID INJURY.
Read and understand the
entire
Safety section before
proceeding.
Figure 4
Off
Start
On
Figure 5
Choke On
Choke Off
WARNING: AVOID INJURY.
Blades will not immediately
stop after pushing PTO knob
down to off position.
Figure 6
Choke Off
Choke On
Figure 7
Fast
Slow
