EN - 29
SPECIFICATIONS
Model Number Model 911373 Model 911375 Model 911379
Model Razor
Description Push Self-Propelled Self-Propelled
Electric Start
Length – cm 177,8
Height – cm 119,4
Width – cm 54,6
Actual Weight – kg 41,3 44,5 47,2
Cutting Width – cm 53,3
Cutting Height – cm 2,5 – 10,2
Engine, 4 cycle Subaru
Max Rotation Speed of Cutting
Edge – min
2,800
Governed RPM (May be
different from maximum RPM)
2,750 ± 50
'LVSODFHPHQW – FF
175
Cylinder Bore Cast Iron
Engine Oil Type See engine manual.
Crank Case Capacity – liter 0,59
Oil System Splash
Engine Oil Filter N/A
Spark Plug Gap – mm See engine manual.
Fuel Type Unleaded
Fuel Tank Capacity – liter 1,5
Air Cleaner Paper Element
Starting Recoil Electric/Recoil
Variable Speeds – km/hr N/A 0 – 4,4
Mower Deck 14 Gauge – Stamped Steel
Wheel Diameter – cm 21,3
CE Sound and Vibration (Ref. EN836+4A: 2011)
Oper. Ear Sound Pressure (Lpa)
in dBA
85
Vibration Measure (m/sec2) at
Operator Hands
5,3 2,3 4,2
