Ariston CLAS HE R 12 Installation And Servicing Instructions

27
installation
Table of ue gas exhaust duct lengths
COAXIAL SYSTEM
FLUE TYPE
MAX
LENGTH
DIAMETER
of PIPE
Equivalent
length
45° 90°
C13
Flue gas exhaust and air
suction duct through
external wall in the same
range of pressure
12
16 m
48 m
60/100
80/125
0.5 m
1 m
18
14 m
42 m
60/100
80/125
24
12 m
36 m
60/100
80/125
C 33
Flue gas exhaust and air
suction duct from outside
with roof terminal in the
same range of pressure
12
16 m
56 m
60/100
80/125
18
10 m
49 m
60/100
80/125
24
12 m
42 m
60/100
80/125
C43
Individual or shared ue
gas exhaust and air suction
through ue ducting built
into the building
Note: A specialist ue
system is required
12
16 m
0 m
60/100
80/125
18
14 m
0 m
60/100
80/125
24
12 m
0 m
60/100
80/125
