42
settings - adjustment - problem identication menus
Accessing the settings - adjustment - pro-
blem identication menus
The boiler can be used to manage the heating
system in its entirety.
Navigation within the menus enables the
boiler system + connected peripheral units
to be customised, optimising operation for
maximum comfort and maximum saving. It
also provides important information relating
to the ecient operation of the boiler.
The following menus are available:
The parameters relating to each individual menu
are listed in the following pages.
The various parameters can be accessed
and modied using the meNu/ok button and
programming buttons and . (see g.
below).
To access the Menus, open the cover and proceed
as follows:
1. Press the meNu/ok button; the rst gure 000
will ash on the display.
2. Press the buttons or to select a menu,
for example: “200
3. Press the meNu/ok button; the second gures on
the display will ash, e.g. “210.
Caution! The menus reserved for qualied
technicians may only be accessed after setting
the access code.
4. Press the meNu/ok button; 222 will appear on
the display unit.
5. Press the buttons or to select code
234
6. Press the meNu/ok button to select the sub menu;
the second gures will ash, e.g. “220”.
7. Press the buttons or to select a sub
menu; for example: “230
8. Press the meNu/ok button to access the sub
menu parameters; the three gures will ash, for
example: “230”.
9. Press the buttons or to select a
parameter; for example: “231
10. Press the meNu/ok button to access the
parameter; the display will indicate the value, e.g
“70”.
Note: The parameter value will be displayed for
20 seconds, then will begin to ash in alternation
with the parameter, e.g. “70 > 231.
11. Press the buttons or to select the new
value, e.g. “75”.
12. Press meNu/ok to save the change or press esc to
exit without saving.
To exit, press the esc button until the normal display
screen is restored.
For menus which do not require the access code, it
is possible to pass directly from the menu to the sub
menu.
2 Boiler Parameter
2 1 Service code (234)
2 2 General setting
2 3 C.H. Parameters - Part 1
2 4 C.H. Parameters - Part 1
2 5 Do not use
2 9 Menu 2 Reset to factory setting
3 Solar & Storage
3 0 General setting
3 1 Service code (234)
3 2 Special setting
4 Zone 1 Parameters
4 0 Set-point Zone1
4 1 Service code (234)
4 2 Zone 1 Setting
4 3 Diagnostics
4 4 Zone device mangement
5 Zone 2 Parameters
5 0 Set-point Zone2
5 1 Service code (234)
5 2 Zone 2 Setting
5 3 Diagnostics
5 4 Zone device mangement
5 5 Multizone
7 Test & Utilities
8 Service Parameter
8 1 Service code (234)
8 2 Boiler
8 3 Boiler Temperature
8 4 Don’t use
8 5 Service
8 6 Statistics
8 7 E@sy - NOT ACTIVE
8 8 Error History
programmiNg
buttons
Menu/Ok button
