Ariston CLAS HE R 12 - Overall Dimension; Minimum Clearances

8
product description
200
200
120
120
85
77
122
25
595
49
161
292 (12-18-24 kW)
362 (30 kW)
135
162
665
44.5
Overall Dimensions
450
300
250
5
5
Minimum clearances
In order to allow easy
access to the boiler for
maintenance operations,
the boiler must be installed
in accordance with the
clearances stated.
