MAINTENANCE GUIDE
1
2
3
5
4
6
7
8
9
LEGEND
1. Burner 6. Mixing tube
2. Fan 7. Detection electrode
3. Air inlet 8. Ignition electrode
4. Gas inlet 9. Spark generator
5. Gas valve
4. BURNER UNIT
