SETTINGS - ADJUSTMENT - PROBLEM IDENTIFICATION MENUS
4 4 ZONE DEVICE MANAGEMENT
4 4 0 NOT PRESENT
5 ZONE 2 PARAMETER
5 0 ZONE 2 TEMPERATURE SETTING
5 0 0 NOT PRESENT
5 0 1 NOT PRESENT
5 0 2 NOT PRESENT
5 1 Entering access code 222 press the programming "+" button to
select 234 and press the meNu button
5 2 CYLINDER SETTING
5 2 0 Heating appliance temperature value setting 0 = from 20 to 45°C (low temperature)
1 = from 35 to 85°C (high
temperature)
1 select in the appliance type base
5 2 1 Basic heating control type selection type depending
on the peripheral devices connected
0 = fixed flow temperature
1 = device On/Off
2 = ambient sensor only
3 = external sensor only
4 = ambient sensor + external sensor
0 To activate heating control, press
the AUTO button. The Auto light is
illuminate
5 2 2 NOT PRESENT
5 2 3 NOT PRESENT
5 2 4 NOT PRESENT
5 2 5 Zone 2 heating maximum temperature setting 35 to + 82°C 82 if parameter 420 = 1
20 to + 45°C 45 if parameter 420 = 0
5 2 6 Zone 2 heating minimum temperature setting 35 to + 82°C 35 if parameter 420 = 1
20 to + 45°C 20 if parameter 420 = 0
5 3 DIAGNOSTICS
5 3 0 NOT PRESENT
5 3 1 NOT PRESENT
5 3 2 NOT PRESENT
5 3 3
Zone 2 set temperature
5 3 4
Zone 2 heat request
0=OFF
1=ON
5 3 5
Zone 2 Pump status
0=OFF
1=ON
5 4 ZONE DEVICE MANAGEMENT
5 4 0 NOT PRESENT
5 4 1 NOT PRESENT
5 4 2 NOT PRESENT
5 5 MULTIZONE
5 5 0 NOT PRESENT
5 5 1 NOT PRESENT
7 TEST & UTILITIES
7 0 0 Function test - Cleaning
turn the encoder to select the operating mode
t-- = funct. at Max heating power t-- activation can also be obtained by
pressing the Reset button for 10
seconds. The function is deactivated
after 10 minutes or by pressing Reset
7 0 1 Bleed cycle press Menu
8 PARAMETER FOR TECHNICAL ASSISTANCE
8 1 Entering access code 222 press the programming "+" button to
select 234 and press the meNu button
8 2 BOILER
8 2 0 NOT PRESENT
8 2 1 Fan status ON or OFF
8 2 2 Fan speed (x100) rpm
8 2 3 NOT PRESENT
8 2 4 NOT PRESENT
menu
sub-menu
Parameter
Description value
default setting
