MAINTENANCE GUIDE
LEGEND
1. Burner
2. Fan
3. Silencer
4. Gas inlet
5. Air inlet
6. Gas valve
7. Mixing tube
8. Detection electrode
9. Ignition electrode
10. Spark generator
4. BURNER UNIT
1
8
3
2
7
6
10
10
9
5
4
