settings - adjustment - problem identication menus
menu sub-menu parameter description value default setting
2 BOILER PARAMETER SETTING
2 1 Entering access code 222 press the programming "+" button to select 234
and press the menu button
2 2 BOILER GENERAL SETTING
2 2 0 Slow ignition 0 to 99 60 RESERVED FOR SAT
2 2 1 Minimum ambient temperature for
antifreeze activation
from 2 to 10 °C 5 Activated only with the modulating peripheral
device (optional)
2 2 2 NOT PRESENT
2 2 3 Underoor thermostat or zone 2 ambient
thermostat selection
0 = Floor safety thermostat
1 = Zone 2 ambient thermostat
0
2 2 4 Mechanical timer connection authorisation 0 = Absent
1 = Present
0 to be modied if mechanical timer is present
(optional)
2 2 5 Heating ignition delay 0 = Deactivated
1 = 10 seconds
2 = 90 seconds
3 = 210 seconds
0 Activated only with zone 2 interface (optional)
2 2 6 NOT PRESENT
2 2 7 Flue gas sensor authorisation
CANNOT BE MODIFIED
0 = Deactivated
1 = Activated
0 RESERVED FOR TECHNICAL ASSISTANCE Only if
the PCB is changed
2 2 8 Boiler Version
CANNOT BE MODIFIED
0 to 5 0 RESERVED FOR TECHNICAL ASSISTANCE Only if
the PCB is changed
2 3 BOILER PARAMETER  PART 1
2 3 0 NOT PRESENT
2 3 1 Maximum heating power setting 0 to 99 see the "gas setting" table, information on page
30
2 3 2 Domestic hot water maximum RPM
percentage
CANNOT BE MODIFIED
0 to 99 RESERVED FOR TECHNICAL ASSISTANCE Only if
the gas or PCB is changed
see "gas setting" table
2 3 3 Minimum RPM percentage
CANNOT BE MODIFIED
0 to 99
2 3 4 Heating maximum RPM percentage
CANNOT BE MODIFIED
0 to 99
2 3 5 Selection of ignition delay type when
heating
0 = Manual
1 = automatic
1 see section on "gas setting"
2 3 6 Ignition delay when heating timer setting from 0 to 7 minutes 3
2 3 7 Post-circulation when heating from 0 to 15 minutes or continuous 3
2 3 8 Circulation pump operating type 0 = Low Speed
1 = High Speed
2 = Modulating
2
2 3 9 Setting the Delta T
Circulation pump modulation
from 10 to 30 °C 20 to be set with operation of the circulation pump
in modulating mode
These parameters allow the ow and return temperature dierence to be set, which determines whether the circulation
pump switches from low to high speed
E.g.: param. 239 = 20 and ∆T > 20°C- the circulation pump runs at high speed. If ∆T < 20 - 2°C the circulation pump runs at
low speed. The minimum waiting time for changing speed is 5 minutes.
