MAINTENANCE GUIDE: GENUS PREMIUM
4.3 BURNER
BURNER
Tools
Time
15 min
1
Remove the silencer
Isolate the gas supply. Remove the
four screws and disconnect the
gas pipe from the gas valve
Pull the assembly towards
you
2
Remove the three screws to free
the burner door
Pull the burner toward you
1. Stainless Steel Burner
2. Ignition electrode
3. Detection electrode
Power Length
18 KW 72.5 mm
25 KW 104.6 mm
30 KW 135.8 mm
38 KW 167 mm
