Ariston Clas System 28 FF - Fun; Air Pressure Switch

60
maintenance guide
4.5 FAN
FAN
Tools Time
5 min
1
Disconnect the fan wires
Remove the air pressure switch support and the
condensate collector
2
4.6 AIR PRESSURE SWITCH
Remove the four screws and pull the fan
towards you
AIR PRESSURE SWITCH
Tools Time
4 min
1
Disengage the air pressure switch by
unlock the four clamps and pivot it
towards you
Disconnect the air
pressure switch wires
Fan
Air pressure switch
