26
OPERATION AND FUNCTIONS
INPUT Control Object
None Comp.
CONTENTS REMARKS
It is linked with comp.
INPUT Control Object
Refrigerator Door
Freezer Door Lamp
Home-Bar Door
(Refreshment Center)
CONTENTS REMARKS
1) Control of Refrigerator Compartment Lights
R lights turn ON/OFF by R-door switch (ON/OFF).
For 10 minutes after sensing door open, the lights turn off automatically though
door close is not sensed.
2) Control of Freezer Compartment Lights
F lights turn ON/OFF by F-door switch (ON/OFF).
For 10 minutes after sensing door open, the lights turn off automatically
though door close is not sensed.
3) R-lights ON/OFF by Home-Bar door opening
R-lights turn ON for 10 minutes after sensing HOME-BAR switch open.
4) DISPENSER lamp control
DISPENSER lamp turns ON/OFF by DISPENSER SW.
Dispenser Lamp turns ON for 5 seconds after sensing switch close.
Demonstration Function
INPUT Control Object
"
fridge set."
/"water" button , Door switch
COMP
F-FAN
R-FAN
CONTENTS REMARKS
1. Start
Push "WATER" button 5 times while pushing "fridge set" button simultaneously.
2. Control
1) All other electrical components are OFF except for F-fan / R-fan.
2) Fan Control
DOOR OPEN FAN ON / DOOR CLOSE FAN OFF
3. Stop or Termination
1) During Demo mode push "water" button 5 times while pushing "fridge set."
button simultaneously.
2) Power in again.
3-15. Home Bar (Refreshment Center) Heater
3-16. Control of Interior Lights
3-17. Demonstration
