31
OPERATION AND FUNCTIONS
3-21. Dispenser Control Function
Control Object
Dispenser switch
Button (Water / Cubed Ice / Crushed Ice)
Ice Maker Lock Button
Freezer Door Switch
Dispenser Lamp
Crusher Motor
Flap Solenoid
Crusher Solenoid
Dispenser Water Valve
Contents
Remark
1) Button to select Water / Cubed Ice / Crushed Ice
( Mode change : Water --> Cubed Ice --> Crushed Ice )
2) Ice Maker Lock Button
* Icemaker Lock function and its LED turn ON/OFF by pressing the button.
Water LED turns ON as default mode.
The LED of each mode turns ON by pressing its button.
( If dispaly switch makes error during operation of a mode, its LED tuns OFF.)
When Icemaker Lock button is pressed ;
- Icemaker Lock LED turns ON.
- If it is in the mode of Cubed Ice or Crushed Ice, the mode is changed to Water
and Water LED turns ON.
- If there is no button input for 1 hour after selecting Cubed Ice or Crushed Ice
the mode turns to Water(default).
Input
* Initial Mode : Water
3) Display
* Selected icon LED turns ON and others are OFF.
