24 / GB
ADDITIONAL FUNCTIONS
PTo set the programme for one of the additional functions, press
OK.
Turn the knob and select:
- Complete menu
Press the OK button.
Turn the knob and select:
- CH setting
Press the OK button.
Turn the knob and select:
- HOLIDAY FUNCTION (in heating mode only)
The holiday function deactivates heating during holiday periods.
Press the OK button.
Turn the knob and select:
- ON (activates the function)
- OFF (deactivates the function)
Press the OK button.
If ON is selected, turn the knob to set the date of return from the
holidays.
This will enable the system interface to resume operating - at the
pre-set date - in the previously set mode.
Press OK to save the settings; the display will return to the pre-
vious visualisation.
In the active sources page, when the holiday function is active
the “
” icon appears.
Turn the knob and select:
- THERMOREGULATION
The Thermoregulation function automatically sets the system’s
operating regime based on the type of installation and envi-
ronmental conditions.
The temperature regulation of a building consists in maintaining
the indoor temperature constant regardless of variations in the
outside temperature.
Press the OK button.
Turn the knob and select:
- ON (activates the function)
- OFF (deactivates the function)
Press OK to save the settings; the display will return to the pre-
vious visualisation.
In the active sources page, when the Auto function is active the
“
”. icon appears.
Room temperature adjustment with AUTO function active.
If the heating / cooling water temperature does not match the
desired value, it can be increased or decreased using the “set
heating temperature” or “set cooling temperature” parameter.
The correction bar appears on the display. Press OK to confi rm
the setting, or press the back button “” to return to the previous
screen without saving
The display visualises the correction bar. Press OK to confi rm
the correction, or press the back button “
“ to return to the
previous visualisation without saving the settings.
Turn the knob and select:
- SPECIAL FUNCTIONS
(where present)
This function limits the power of the heat pump system to reduce
the noise.
Press the OK button.
Turn the knob and select:
- Quiet Mode Activation
- ON (activates the function)
- OFF (deactivates the function)
- Quiet Mode start time
(sets the activation time)
- Quiet Mode end time
(sets the deactivation time)
- PV Delta T DHW setpoint temp.
Thus function increases the domestic water setpoint when ex-
tra power is available from the photovoltaic system.
Press the OK button to confi rm the selection.
Press the back button “
“ to return to the previous screen.
Press the back button “
“ to return to the previous screen.
- System Performance
you can see the energy performance of the installed system.
Press the OK button. Turn the knob and select:
- Menu
Press the OK button. Turn the knob and select:
- System Performance
Press the OK button. Turn the dial and select:
- Active sources
- Energy production
- Energy meteringg
- Reset Report
Press the OK button to confi rm your selection.
- Active sources
Displays the energy produced by the solar heating panel over
24 hours, one week or one year.
- Energy production
Displays the energy produced by the solar heating panel over
24 hours, one week or one year.
- Energy metering
shows the estimated electricity consumption in kW/h – in the
domestic water, heating and cooling modes – over the past 4
months
ENERGY METERING
The energy consumption measurement system integrated in
this product is based on an estimate.
Therefore, there may be di erences between the actual con-
sumption (or that measured by another system) and the one
displayed.
Turning the knob allows for selecting the consumption data rela-
tive to one of past four months.
- Consumptions history
This report shows the gas and electricity consumption histo-
gram in kW/h based on the times selectable through the knob
(24h, weekly, monthly, annual).
Turn the knob to view:
- Heating mode consumption report
- Domestic water mode consumption report
- Cooling mode consumption report
- Reset Report
Resets all reports.
