Aritech 2X-A Series Installation Manual

Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 129
Individual device diagnostics
Individual device diagnostics options are shown in the table below. Where a
polling mode is not supported by a device, the panel uses the default polling
mode.
Note: Detailed device diagnostics may be requested by your regional technical
support office to help troubleshoot technical issues. Use the following tests as
instructed by the technical support team and give the test results to them for
further analysis and assistance.
Table 70: Individual device diagnostics tests
Polling mode [1]
Description
STA_AB, STA_A, STA_B
Configures status polling mode
AV1_AB, AV1_A, AV1_B
Configures analogue value 1 polling mode
AV2_AB, AV2_A, AV2_B
Configures analogue value 2 polling mode
GRP_AB, GRP_A, GRP_B
Configures group status polling mode
[1] AB, A, and B indicate the loop channel used.
Individual device diagnostics values are shown in the table below.
Table 71: Individual device diagnostics values
Value
Description
Val1
Analogue value 1 (AV1, AV2) or status value (STA) [1]
Val2
Device type
Val3
Device address
Val4
Device status [2]
Val5
CRC of the reply [2]
[1] The analogue values displayed are the raw binary values received from the device.
[2] These values may not be available for all devices.
