ATS4000 Installation and Quick Programming Guide 7
1. Specification ATS4000 Main Board (no accessories)
Description:
Max. output current: Max. 2 Amp
Current consumption: 200 mA nominal
End of line resistors:
4,7 kΩ, 5 %, 0,25W
Enclosure dimensions (L x W x D): 360 mm x 260 mm x 82 mm
Operating temperature: 0 °C to + 50 °C
Humidity: 95% non-condensing
2. Specification External terminals
Part Terminal Description Min Typ Max
23 VACAC Secondary AC transformer
connection
58 VA
13,6 13,8 14,0 VDC
J17
BATT Battery connection
16 VA
J14 AUX.POWER Auxiliary Power output 13,6 13,8 14,0 VDC
13,6 13,8 14,0 VDCEXT
STRB
External Siren & Strobe
2A
13,6 13,8 14,0 VDC
J13
INT Internal Siren
1A
14,0 VDCJ9 BELL NO or NC contact Low Voltage
2A
3. Values for end-of-line resistors.
The following list contains the values to be used for end-of-line resistors. Both the resistance and the voltage
over the zone are shown. The voltage will differ for other power supply voltages measured.
To get the current power supply voltage measure the voltage over the zone when it is open. The end of line
resistor used is based on the setting for the end of line resistor code as programmed in the system options
(see ATS4000 programming guide).
EOL code 0 (10 kOhm resistors)
Status Rzone (kOhms) Vzone (V)
Short circuit < 2 < 4.14
Active zone 2.7 - 6.4 5.07 - 8.01
Normal zone 7.1 - 14.2 8.34 - 10.42
Active zone 18.1 - 70 11.01 - 13.01
Open circuit > 170 >13.01
EOL code 1 (4.7 kOhm resistors)
Status Rzone (kOhms) Vzone(V)
Short circuit < 0.6 < 1.8
Active zone 1.02 - 2.4 2.47 - 4.69
Normal zone 3.3 - 5.2 5.72 - 7.28
Active zone 7.2 - 15 8.34 - 10.56
Open circuit > 25 >11.71
