PROGRAMMING MAP
1. Zone Database 1. Zone number
Zone Type
0. No type programmed. 22. Dis. Delay reset/Arm Alm 44. Fire door with almgrp restr.
1. Disarmed alarm 23. Camera 1 count 45. (Event flag/Arm.Alm) Almgrp. restr.
2. Armed alarm 24. Camera 2 count 46. Disarm Alm/Arm Gen. Alm.
3. Entry exit alarm 25. Camera 3 count 47. Dis. Alm Susp./Arm Gen. Alm
4. Access zone 26. Camera 4 count 48. Camera 1 film out
5. 24 hour alarm 27. Technical with Report 49. Camera 2 film out
6. Pulsed keyswitch 28. Armed Alarm with reset 50. Camera 3 film out
7. Camera suspicion zone 29. 24 Hour Alarm with reset 51. Camera 4 fim out
8. Disarmed delay /Arm gen. alarm 30. Fire door with reset 52. Camera 5 fim out
9. Reset delayed input 31. Latching keyswitch 53. Camera 6 fim out
10. Do Not use! 32. Armed zone to event flag 54. Camera 7 fim out
11. Disarmed delay alarm 33. 24 hr Alarm and Inhibit 55. Camera 8 fim out
12. Restart exit timer 34. Area Dis/Almgrp restr. Arm 56. Fire door if No TZ41
13. Entry/Exit no arm check 35. Area Almgrp restr. Arm Only 57. Technical Report And Screen
14. Access without arm check 36. Camera 5 count 58. Technical Screen
15. Fire door 37. Camera 6 count 59. 24 hr Alarm If No Tz 41
16. 24-hour local mains fail 38. Camera 7 count 60. Exit Terminator
17. Do Not use! 39. Camera 8 count 61. Entry exit hold off reporting
18. 24-hour local comms fail 40. Dis. Susp.Delay /Arm Alm 62. Acces hold off reporting
19. Comms fail led 41. Fire door Entry/Exit 63. Entry check no arm check
20. Zone to Event Flag 24-hr 42. Fire door w. code Entry/Exit holdoff reporting
21. Firedoor with usercode 43. Disarm zone to Event Flag 64. acces no arm check holdoff reporting
1. Zone name
2. Zone type
3. Reporting of zone
6. Report alarm to CS 3
4. Report alarm to CS 1
5. Report alarm to CS 2
7. Report alarm to CS 4
8. Enable ALI for this zone
9. Enable engineer reset for alarms
10. Enable engineer reset for tampers
13. Area/alarm group assignment
11. Disable inhibit of the zone
12. Select voice message
14. Test option
15. Zone event flag
16. Siren event program in area DB
17. Keypad Buzzer
20. Trigger event flag 3, armed alarm
18. Make all events 24 hour
19. Trigger event flag 2, armed alarm
21. Trigger event flag 4, armed alarm
22. Trigger event flag 5, armed alarm
23. Trigger event flag 6, disarmed alarm
24. Trigger event flag 7, disarmed alarm
27. Trigger event flag 10, armed alarm
25. Trigger event flag 8, 24hr alarm
26. Trigger event flag 9, armed alarm
28. Trigger event flag 11, armed alarm
31. Trigger camera event in area DB
29. Trigger event flag 13, disarmed alarm
30. Trigger zone event flag when active
32. Print zone when active
