P/N 146655999-1 (ML) • REV G • ISS 14DEC20 7 / 48
Remote Self-Test
A self-test routine will commence when a negative voltage is
applied to the TEST terminal. The Anti-Mask detector
constantly self-checks and will operate the Fault/A-M relay if an
internal fault condition is detected.
Accessories
Carrier Fire & Security can provide a handheld walk tester
DI601-WT to aid installations.
Specifications
Programmable: 10 m, 20 m or 30 m
10 to 70° detection angle, 30 x 24 m
coverage max.
−45° to +45° pan, tilt +45°
28 zones for each detection element, which
can be masked with the curtain sliders
Double silicon shielded quad element
eliminates 50,000 lux of white light
Top PCB
Red: Programming LED
Sensor PCB
Blue: Detector alarm
Red(small): Anti-mask alarm
Infrared: Walk tester communication
Red: PIR active
Green: Microwave active
Operating frequency
(country specific):
DDI602AM-F1
DDI602AM-F2
DDI602AM-F3
10.525 GHz
10.587 GHz
9.900 GHz
Maximum power output
E.I.R.P.
DDI602AM-F1
DDI602AM-F2
DDI602AM-F3
Silent, solid state, magnetically immune.
Volt free relay, signal contact 24 VAC/DC at
50 mA with an integral 25 Ω series resistor.
Alarm time 5 seconds.
Volt free relay, signal contact 24 VAC/DC at
50 mA with an integral 25 Ω series resistor.
Alarm time 5 seconds.
Volt free relay, signal contact 24 VAC/DC at
50 mA with an integral 25 Ω series resistor
21 mA (12 V nominal)
Standby 41 mA MAX
Analogue (thermistor) and digital sensitivity
adjustment
Digital microprocessor with nonvolatile
memory
Output test mode with LED indication.
Option to disable LEDs.
High impact ABS plastic with HDPE cover,
UV stabilized
Variable up to 6 m
Optimum height 3 m for full range
PLACED ON THE MARKET BY:
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
“AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE
AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
EN 50130-5
EN 50131-2-4, Grade 3, Class IV
Certified by Telefication B.V.
Note: EN 50131-2-4 compliant only when
mounted at 1.5 and 3 m
IP55
This product meets the environmental
requirements of EN 50130-5.
European Union
directives
Carrier Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of all applicable rules
and regulations, including but not limited to the
Directive 2014/53/EU. For more information see:
www.firesecurityproducts.com
Product may contain substances that are also
Candidate List substances in a concentration
above 0.1% w/w, per the most recently published
Candidate List found at ECHA Web site.
Safe use information can be found at
https://firesecurityproducts.com/en/content/intrusi
on-intro
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
recyclethis.info
Only use the listed models in the following
countries:
Albania, Argentina, Australia, Belgium, Brazil,
Denmark, Holland, Hungary, Iceland, Indonesia,
Latvia, Lithuania, Malta, Norway, Portugal,
Russia, South Africa, Spain, Sweden, Taiwan,
Ukraine, USA.
