FP2000 SERIES ANALOGUE ADDRESSABLE FIRE PANEL: USER INSTRUCTIONS Version 3.1
APPENDIX B
INSTALLING NEW PRINTER PAPER
The printer is shipped with a roll of paper loaded, but not fed to the printer head. This is to
prevent damage. Before use, feed the paper in as follows:
1. Open the door of the fire panel and locate the printer (bottom left hand side
internally on the door).
2. Loosen the two retaining screws as shown in Figure B.1 below and gently remove
the printer.
Figure B.1: Printer Retaining Screws
May 1997 Product Code: LKFP2403 Document No: 970508/205/M Page B-1
