28
The Tempo should not be loaded with a weight in excess of the lowest rated attachment fitted
(see table below for lifter and attachments maximum lifting capacities).
MAXIMUM CAPACITIES OF TEMPO
All slings (except Extra Extra Large - XXL) - 190kg (420lbs)
Extra Extra Large sling - XXL - 200kg (440lbs)
Lifter + Dedicated jib + 4 point spreader bar - 200kg (440lbs)
Lifter + Dedicated jib + 4 point P.P.P. spreader bar - 200kg (440lbs)
Lifter + 200mm Extended dedicated jib + 4 point spreader bar - 130kg (286lbs)
Lifter + Dedicated jib + 4 point spreader bar + scale - 200kg (440lbs)
Lifter + Dedicated jib + 4 point P.P.P. spreader bar + scale - 200kg (440lbs)
The capacities given are correct for the lifter configurations listed, but some accessories/additional/optional sub
assemblies may reduce the maximum capacity. Always refer to the maximum weight limit printed on the label
fixed to the lowest rated fitted attachment.
Technical Specification
