8
Slings
A circular label is fitted to the lifter jib for quick
colour to size reference (see “Labels” section).
A range of special purpose slings are available as
accessories, for these or for special size slings,
contact your ARJO representative.
•Note: All Tempo slings will support
190kg/420lbs), note: the extra extra large
sling will support 200 kg (440 lbs) all
slings are coded for size by having
different coloured edge binding as
follows:
Brown - Extra small - XS
Red - Small - S
Yellow - Medium - M
Green - Large - L
Blue - Extra Large - XL
White - Extra Extra Large
Warning: Only use ARJO supplied
slings that are designed to be used with
Tempo. The sling profiles illustrated (see
fig. 2) will help to identify the various
ARJO slings available.
If ARJO Flites (disposable slings) are to
be used with the Tempo, then always refer
to the separate operating instructions for
ARJO Flites, (literature reference part No.
MAX01720), as well as these instructions
before using.
Warning: ARJO slings with head
support have two pockets at the head
section which should contain plastic
reinforcement pieces during use. Always
ensure these reinforcement pieces have
been inserted into the sling pockets before
using the sling.
Product Description/Function
