- 63 -
INSTALLATION
ALL THE OPERATIONS DESCRIBED IN THIS SECTION MUST BE CARRIED OUT EXCLUSIVELY BY
QUALIFIED STAFF.
The Company may no be held liable for any damage caused by incorrect connections or by
operations that are not described in this manual.
STORAGE OF THE UPS AND THE BATTERY BOX
The storage area must have the following characteristics:
Temperature: 0°-40°C (32°-104°F)
Relative humidity: 95% max
PREPARATION FOR INSTALLATION
PRELIMINARY INFORMATION
UPS Models 10 kVA 12 kVA 15 kVA 20 kVA
Nominal power
10000 VA 12000 VA 15000 VA 20000 VA
Operating temperature
0 - 40 °C
Max. relative humidity during operation
90% (non-condensing)
Max. installation height
1000 m at nominal power rating
(-1% Power for every 100 m over 1000 m)
max 4000 m
Dimension W x D x H
320 x 840 x 930 mm
Weight (with batteries)
180 Kg 182 Kg 190 Kg 195 Kg
Dissipated power with nominal resistive
load (pf=0.8) and with back up battery *
0.56 kW
480 kcal/h
1910 B.T.U./h
0.670 kW
580 kcal/h
2290 B.T.U./h
0.765 kW
660 kcal/h
2610 B.T.U./h
1.02 kW
880 kcal/h
3480 B.T.U./h
Dissipated power with nominal
distorting load (pf=0.7) and with charged
battery *
0.49 kW
420 kcal/h
1660 B.T.U./h
0.58 kW
500 kcal/h
1990 B.T.U./h
0.670 kW
580 kcal/h
2290 B.T.U./h
0.90 kW
775 kcal/h
3070 B.T.U./h
Fan capacity at installation premises for
heat dissipation **
300 mc/h 355 mc/h 410 mc/h 545 mc/h
Current dispersed to earth ***
< 7 mA
Protection level
IP20
Cable input
From base / on rear
* 3.97 B.T.U./h = 1 kcal/h
** The following formula can be used to calculate the fan capacity: Q [mc/h] = 3.1 x P
diss
[kcal/h] / (t
a
- t
e
) [°C]
P
diss
is the dissipated power of all the installed apparatus at the installation premises expressed in kcal/h.
ta= environmental temperature, te= external temperature. To account for leaks, increase the value obtained by 10%.
The table shows an example of the fan capacity with (t
a
- t
e
)=5°C and with nominal resistive load (pf=0.8).
(N.B.: The formula applies if ta>te; otherwise an air conditioner should be installed).
*** The dispersion current of the load is added to the dispersion current of the UPS on the earth protection conductor.
