VIEW OF THE UPS CONNECTIONS
Power connections: BATTERY, INPUT, SEPARATE BYPASS (optional), OUTPUT
Connection for remote maintenance bypass command
Connection for external Battery Box temperature probe
Connection for external synchronization signal
Connection for R.E.P.O. (Remote Emergency Power Off) command
Area for the single-phase short-circuit bar
Slot for power relay board
