- 66 -
PRELIMINARY CHECK OF CONTENTS
Having opened the package, start by checking the contents.
UPS BATTERY BOX (optional)
Metal slides, Guarantee document, User manual,
Cd-rom containing the UPS management software,
Serial connecting cable, 4 battery fuses (to be
inserted in the "SWBATT" fuse holders), Short circuit
bar (with 3 fastening screws)
Metal slides, Guarantee document, Cable for connecting
the Battery Box to the UPS, 4 battery fuses (to be
inserted in the "SWBATT" fuse holders)
INSTALLING THE UPS AND THE BATTERY BOX
When installing the equipment, the following points should be considered:
The wheels are to be used exclusively for fine positioning, and thus for small distances only.
The plastic parts and the door are not to be used for gripping or pushing the UPS.
Sufficient space should be left in front of the equipment for it to be turned on/off and maintenance operations to
be performed on it ( ≥ 1.5 mt )
The rear part of the UPS should be set at least 30 cm from the wall, to enable the air blown by the ventilation
fans to flow away correctly
No objects should be left on its top surface
Having set the equipment in position, secure it by engaging the brake rod (see "Front Views of the UPS" point 8) situated
below the connecting terminals.
STEPS TO BE TAKEN TO GAIN ACCESS TO THE TERMINALS OF THE UPS / BATTERY BOX
The operations indicated below are to be performed with the UPS disconnected from the mains
powers, turned off and with all the switches and fuse holders of the equipment open.
Follow the instructions provided below to open the UPS:
Open the door by pressing on the top right-hand area of the door
Remove the terminal and switches cover (see "Front Views of the UPS" ref. 7)
Having completed the installation operations inside the equipment, replace the terminal cover and close the door.
