Aros Flexus FM Series - Dimensions and Operation

- 102 -
UPS Models 10 kVA 12 kVA 15 kVA 20 kVA
Dimensions and weight
Width x Depth x Height 320 x 840 x 930 mm
Type of metal frame
Tower enclosure with wheels for transit, display inset in upper front section. Door
in lower front section giving access to switches and connections
Weight (without batteries) 80Kg 82Kg 90Kg 95Kg
Weight with batteries 180Kg 182Kg 190Kg 195Kg
Operation and efficiency
Operating Mode
True on line double conversion
ECO mode
Smart Active mode
Stand-by Off (Emergency)
Frequency Converter
AC/AC performance in on line mode
≥93.5% ≥94%
AC/AC performance in Eco mode
≥98%
DC/AC performance in backup mode ≥92.5% ≥93.5%
Other features
Noise ≤48dB(A) ≤52dB(A)
Colour RAL 7016
Environmental temperature
(7)
0 – 40 °C
Security Compliance EN 62040-1-1, 2006/95/EC 73/23/EEC and 93/68/EEC directives
EMC Compliance EN 62040-2 cat. C2. 2004/108/EEC, 93/68/EEC and 89/336/EEC directives
Battery Box Models
ET06P480A5-
(6)
ET06V480A0-
(6)
ET06P480M5-
(6)
ET06V480M0-
(6)
Battery
Nominal voltage per branch 240Vdc
Number of batteries/ V 40 / 12 80 / 12
Various
Environmental temperature
(7)
0 – 40 °C
Humidity <95% non condensing
Protections Over current – Short circuit
Safety Compliance EN 62040-1-1, 73/23/EEC and 93/68/EEC directives
EMC Compliance EN 62040-2 cl. C2 - 2004/108/EEC, 93/68/EEC and 89/336/EEC directives
Width x Depth x Height 320 x 840 x 930 mm
Weight 150 Kg 270 Kg
(1)
To keep the output voltage within the indicated precision range, retuning may be necessary following a long period of use
(2)
If the mains frequency falls within ± 5% of the selected value, the UPS is synchronised with the mains. If the frequency is outside
the tolerance range or operating off the batteries, the frequency will be the selected +
0.1%
(3)
Mains/Battery @ 0% -100% load
(4)
@ Mains/ battery/mains @ 0% / 100% / 0% resistive load
(5)
The recharge current is adjusted automatically depending on the capacity of the battery installed.
(6)
The symbol “-” replaces an alphanumeric code for internal use
(7)
20 – 25 °C for longer battery life
(8)
@ 100% load & THDv ≤ 1%
