Antenna Analyzer AIM4170 page 20
Parameter values for both a series and a parallel equivalent circuit are shown as Rs, Ls
(series circuit) and Rp, Lp (parallel circuit). Note that when the phase angle, Theta, is
negative, the equivalent components, Ls and Lp, change to Cs and Cp automatically.
At the top of the graph in the main window, up to five resonant frequencies of the
antenna are displayed. These are the frequencies where the phase angle passes through
zero. At these frequencies, the magnitude of the impedance is a maximum or a
minimum.
The names of the calibration and configurations files being used are shown in the lower
right corner of the data window. The color used to display these file names can be
selected in the configuration file.
