Antenna Analyzer AIM4170 page 33
Automatic Crystal Parameter Calculation
The calculations to find the crystal
parameters are tedious so they have been
combined into a procedure than can be
called from the Data menu. First click
“Measure Crystal”:
Then enter the resonant frequency:
After a few seconds the crystal parameters
will be displayed:
