Fixture Menu
27
Fixture Menu
Note: The small, horizontal arrow in the displays indicates sub-menus. Press the ENTER button to access the sub-menus.
Level 1 Level 2 Level 3 Level 4 Description (Default = bold)
Intensity
Displays the recent intensity level when turning the
dimmer knob in %
CCT
Only in CCT mode:
Displays the recent color temperature when turning
the CCT/HUE knob in K
HUE
Only in HUE mode (only L7-C):
Displays the recent hue when turning the CCT/HUE
knob in ° (0-360°)
GRN
Only in CCT mode:
Displays the recent green / magenta value when turn-
ing the GRN/SAT knob in %
SAT
Only in HUE mode (only L7-C):
Displays the recent saturation when turning the
GRN/SAT knob in %
STATUS
OK
Product ready for operation, no errors OR Error
ERROR
XX.X°C Recent temperature of the light engine
HOUR XXXX t Hours of operation
DMX V X.X Version of the DMX protocol
SW Firmware version
