ARRI L7 - DMX Protocol Details

DMX Protocol
34
DMX Protocol
L7-TT (Tungsten Tuneable)
Overview
*
= Factory default
GN saturation - average equivalents.
Mode 1: 8 bit resolution per function
Mode 2: 16 bit resolution per function
Mode 3: Coarse / fine channel per function
Each of the 256 coarse steps is divided in 256 fine steps. Use
this mode when your lighting control desk does not support true
8 bit, 1 channel
per function
16 bit, 2 channels
per function
Coarse / fine, 2 chan-
nels per function
DMX mode 1
*
DMX mode 2 DMX mode 3
Setting Rosco# Setting Rosco#
Full -Green 3308 Full +Green 3304
1/2 -Green 3313 1/2 +Green 3315
1/4 -Green 3314 1/4 +Green 3316
1/8 -Green 3318 1/8 +Green 3317
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed  open
2
0-255 0-100
Color temperature CCT
2.600 K  3.600 K
3
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99%  -1%
neutral / no effect
1%  99%
full plus green
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed  open
2LO
3HI
0-65535 0-100
Color temperature CCT
2.600 K  3.600 K
4LO
5 HI 0-5.000
5.001-10.000
10.001-29.999
30.000-40.000
40.001-59.999
60.000-65.535
0-7
8-15
16-46
46-61
61-92
92-100
GN saturation
neutral / no effect
full minus green
-99%  -1%
neutral / no effect
1%  99%
full plus green
6LO
