ARRI L7 - Page 37

DMX Protocol
37
L7-C
Overview
*
= Factory default
GN saturation - average equivalents.
Mode 1: White & RGBW, 8 bit resolution per function
8 bit, 1 channel
per function
16 bit, 2 channels
per function
Coarse/fine, 1-2 chan-
nels per function
DMX mode 1
*
White & RGBW
DMX mode 6
White & RGBW
DMX mode 11
White & RGBW
DMX mode 2
White
DMX mode 7
White
DMX mode 12
White
DMX mode 3
White & HSI
DMX mode 8
White & HSI
DMX mode 13
White & HSI
DMX mode 4
RGBW
DMX mode 9
RGBW
DMX mode 14
RGBW
DMX mode 5
HSI
DMX mode 10
HSI
DMX mode 15
HSI
Setting Rosco# Setting Rosco#
Full -Green 3308 Full +Green 3304
1/2 -Green 3313 1/2 +Green 3315
1/4 -Green 3314 1/4 +Green 3316
1/8 -Green 3318 1/8 +Green 3317
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Color temperature CCT
2.800 K → 10.000 K
3
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99% → -1%
neutral / no effect
1% → 99%
full plus green
4
0-255 0-100
Xfade to color
White → RGBW color
5
0-255 0-100
Intensity red
0% → 100%
6
0-255 0-100
Intensity green
0% → 100%
7
0-255 0-100
Intensity blue
0% → 100%
8
0-255 0-100
Intensity white
0% → 100%
