ARRI L7 - Page 39

DMX Protocol
39
Mode 4: RGBW, 8 bit resolution per function
Mode 5: HSI, 8 bit resolution per function
Mode 6: White & RGBW, 16 bit resolution per function
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Intensity red
0%  100%
3
0-255 0-100
Intensity green
0%  100%
4
0-255 0-100
Intensity blue
0%  100%
5
0-255 0-100
Intensity white
0%  100%
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Hue
0° → 360°
3
0-255 0-100
Saturation
0 → full saturated
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed → open
2LO
3HI
0-65.535 0-100
Color temperature CCT
2.800 K → 10.000 K
4LO
5 HI 0-5.000
5.001-10.000
10.001-29.999
30.000-40.000
40.001-59.999
60.000-65.535
0-7
8-15
16-46
46-61
61-92
92-100
GN saturation
neutral / no effect
full minus green
-99% → -1%
neutral / no effect
1% → 99%
full plus green
6LO
7HI
0-65.535 0-100
Xfade to color
White  RGBW color
8LO
9HI
0-65.535 0-100
Intensity red
0%  100%
10 LO
11 HI
0-65.535 0-100
Intensity green
0%  100%
12 LO
13 HI
0-65.535 0-100
Intensity blue
0%  100%
14 LO
15 HI
0-65.535 0-100
Intensity white
0%  100%
16 LO
