ARRI L7 - Page 41

DMX Protocol
41
Mode 9: RGBW, 16 bit resolution per function
Mode 10: HSI, 16 bit resolution per function
Mode 11: White & RGBW, Coarse/fine per function
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed → open
2LO
3HI
0-65.535 0-100
Intensity red
0%  100%
4LO
5HI
0-65.535 0-100
Intensity green
0%  100%
6LO
7HI
0-65.535 0-100
Intensity blue
0%  100%
8LO
9HI
0-65.535 0-100
Intensity white
0%  100%
10 LO
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed → open
2LO
3HI
0-65.535 0-100
Hue
0°  360°
4LO
5HI
0-65.535 0-100
Saturation
0  full saturated
6LO
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Color temperature CCT
coarse
2.800 K → 10.000 K
4 0-255 0-100 Color temperature fine
5
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99% → -1%
neutral / no effect
1% → 99%
full plus green
6
0-255 0-100
Xfade to color
White → RGBW color
7
0-255 0-100
Intensity red coarse
0% → 100%
8 0-255 0-100 Red fine
9
0-255 0-100
Intensity green coarse
0% → 100%
10 0-255 0-100 Green fine
11
0-255 0-100
Intensity blue coarse
0% → 100%
12 0-255 0-100 Blue fine
13
0-255 0-100
Intensity white coarse
0% → 100%
14 0-255 0-100 White fine
