ARRI L7 - Page 43

DMX Protocol
43
Mode 14: RGBW, Coarse / fine channel per function Mode 15: HSI, Coarse / fine channel per function
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Intensity red coarse
0% → 100%
4 0-255 0-100 Red fine
5
0-255 0-100
Intensity green coarse
0% → 100%
6 0-255 0-100 Green fine
7
0-255 0-100
Intensity blue coarse
0% → 100%
8 0-255 0-100 Blue fine
9
0-255 0-100
Intensity white coarse
0% → 100%
10 0-255 0-100 White fine
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Hue coarse
0 → 360°
4 0-255 0-100 Hue fine
5
0-255 0-100
Saturation coarse
0 → full saturated
6 0-255 0-100 Saturation fine
