ARRI M18 - Stirrup; Removing the Stirrup

M18 – Service Manual Page 17 of 19
Stirrup
Remove lens door, reflector, SSA and housing
Remove 3 screws on the inside of the front
casting (Torx 20.)
Remove two screws (Torx 15) from the internal
baffle. Remove the front casting.
Loosen 4 screws (Torx 20.) Two on each side
on the brackets. Do not remove!
Slide out the stirrup
