ARRI M18 - Disassembling Order

M18 – Service Manual Page 5 of 19
Disassembling Order
The graphic shows the order in which the components must be removed to ensure a proper repair. All
components which are not preceded by a further assembly group can be exchanged directly.
WARNING: Before starting the repair please take note of the safety instructions!
Make sure that the lamp head is fully disconnected from the mains and cooled down
for a minimum of 30 minutes before opening the cover or beginning the repair.
Lamp
Cables
Ignitor
Lens
Holder
UV
Protection
Glass
Reflector
Safety
Switch
Housing
Stirrup
IMPORTANT NOTE: SEE SERVICE PARTS MANUAL FOR CORRECT VERSIONS OF
PARTS AS PER SERIAL NUMBER
