DMX Monitor
When valid control data is received, the SkyPanel automatically opens page one of the DMX monitor in the
display. The top right corner will say DMX, and the top left corner will note any special settings such as
RGBW cal. or Low End Mode, when they are active.
In addition, there is a second page on the display that shows various values and parameters of the fixture.
DMX values are not listed here, instead, aspects such as intensity and CCT are written as plain text. This
is a useful function for troubleshooting in a control network.
Rotating the encoder switches between the pages. The length of page two will change depending on what
mode and values are being sent.
Information displayed on page one:
• DMX mode and description
• DMX address and channels used
• DMX footprint size
Information displayed on page two
The information displayed on page two of the DMX monitor is dependent on the active DMX mode:
Up to 7 additional parameter can be displayed, depending on which effect is active. See the DMX Protocol
Specification document for more information.
Individual Light Engine control modes do not display their color information on the DMX Monitor screen.
DMX mode utilizing... Information
All DMX modes Intensity
Cross-fade, if active
X-Fade (cross-fade)
Note: If the X-Fade is at 0 or 255, only the active color control information will
be displayed.
CCT
CCT
+/- Green
RGBW
Red
Green
Blue
White
HSI
Hue
Sat
Gels
(Base) CCT
Color Match
Brand
Cat. (Category)
Name
No. (Gel Number)
X-Trans (Transition Type)
XY
x Value
y Value
X-Trans (Transition Type)
Source matching
Cat. (Category)
Source
Effects Effect
