TRINITY 2 balance quick guide 20
Side to Side Balance
After the Top Stage and the Pendulum had been centered, the
Battery Hanger is now the reference for the side to side adjustment.
Do not move the Top Stage or the Pendulum out the
previously determined neutral centerposition!
► Now a sideways movement becomes visible.
► To bring the entire rig into a vertical position, the camera inside
the ring needs a side to side
adjustment.
Side to Side Lock
► Open the side locking mechanism by pushing the clamp lever to
the left.
