2 VIP2262 Installation Guide
Overview
Front Panel
The illustration below and the table following it describe the front-panel features of the
VIP2262.
Key Item Function
1 POWER Press to turn the VIP2262 on or off.
The LED (just to the left of the POWER key) lights green to
indicate the unit is powered on and active. When active, LED
flashes each time you press a key on the remote control.
The LED lights orange when the unit is in Standby mode.
2 USB Universal Serial Bus (USB 2.0) connector.
3 LINK LED lights green when receiving a video stream.
4 HD LED lights blue when receiving a High-Definition program.
5 RECORD LED lights red when a recording is in progress.
6 MENU Press to display the menu.
7 Up/Down
arrow keys
Left/Right
arrow keys
OK
center key
Press to change the channel (channel up/channel down) and
to navigate through on-screen program guide and menu
Press to navigate through on-screen program guide and
menu
Press to select programs or menu options
