Spur/Pinion Mesh Adjustment
1 2 3
Tools Required
5.5 & 7mm Nut Driver or Cross Wrench
Slipper Clutch Adjustment
WARNING:
A loose slipper will damage the friction pads. If
the slipper is too tight it may damage the transmission.
Tools Required
2mm Hex Driver
2
1
5.5 & 7mm Nut Driver or Cross Wrench
ARRMA-RC.COM/
SUPPORT/
2mm Hex Driver
ARRMA-RC.COM/
SUPPORT/
Factory Setting-Werkseinstellung-Réglage d'usine-Padrón-
󱐪󱖲󴷮󶲖󱐪󶶥󲡲󶼌󶛡
MEGA/BLS/BLX
1. Fully tighten locknut clockwise. Kontermutter festziehen im Uhrzeigersinn. Serrer l’écrou complètement. Apriete completamente con-
tratuerca en sentido horario.
󱶼󱎘󵜱󳽗󴧪󲷽󵪪󲠦󵚸󲟩󱙁󲔗󳽗󰆎󱶼󱎘󰇯󰉫󰉁󰈭󰉈󰉁󰉆󰈖󲡲󴰸󱤎󰈎󰇯󴀐󰈅
2. Loosen 3 turns. Rückgängig 3 Umdrehungen. Desserrez les 3 tours. Afloje 3 turnos.
󲦮󲄰  󱤸󰆎 󰈽󰉺󰉱󰈖󴀙󰈅󰈂󰇝󰆎
