28 of 36
EN
(to be done every 6 months or after 1000 kg
burnt pellets)
Cleaning of the combustion chamber
• Open the door and remove the hearth, the bra-
zier and the ash box;
•
Remove the ap holding the inner wall and pull
this and the two side walls out with due cau-
tion (
Pict
. 15);
• Remove the ame shield. Let it run towards the
door, remove the support aps and lower it until
you can pull it out (Pict. 16);
• Spray some suitable loosening product on the
screws fastening the upper and lower panels of
the combustion chamber. Wait until the screws
are loosened and remove them using a suitable
tool. Remove the panels;
• Use a paddle or an aspirator ro remove any even-
tual ash rests or incrustations. Remove in correct
order all the removed parts. Remember to lubri-
cate the scres fastening the panels.
Pellet insert back side
• With due caution lift the pellet insert a bit and remo-
ve it from the check pin of 5 mm.;
• Pull the pellet insert out of the replace. You need
four of you at the four sides of the pellet insert. Lift
it by hand and put it on a level surface;
• Using a brush or an aspirator remove any eventual
ash or dust rests. Installa the pellet insert again: Place
it on the support and push it slowly until it reaches
the apposite check pin;
• Check that the ue system lies perfectly in the T pipe.
Pict. 15: how to remove the sides
Pict. 16: how to remove the ame protection
Cleaning the clearing system
Until a reasonable experience is acquired regarding the operating conditions, it is advisable to
perform this maintenance on at least a monthly basis.
• Remove the electrical feed cable;
• Remove the cap from the T-joint and proceed with the cleaning of the ducts. If necessary, at
least for the rst few times, call in qualied personnel;
• Carefully clean the smoke discharge system: for this, contact a professional chimney sweep;
• Once a year clean the dust, cobwebs, etc. from the zone behind the internal covering panels,
paying particular attention to the fans.
Cleaning the fans
The pellet insert is furnished with fans (environmental and smoke) positioned at the rear and
below the pellet insert.
Eventual deposits of dust or ash on the blades of the fan can cause an
imbalance in the fans leading to noisy performance.
It is, therefore, necessary to clean the fans at
least once a year.
Since said operation requires dismantling several parts of the pellet insert, have the fans cleaned
only by our Technical Assistance Centre.
Supplementary maintenance
