950-0047-04, Rev. A English
950-0047-04A Page 1 of 69
Synergy
UHD4
System
Instructions for Use Manual
AR-3200-0020
AR-3200-0021
AR-3200-0022
AR-3200-0023
AR-3210-0018
AR-3210-0021
AR-3210-0022
AR-3210-0023
AR-3210-0025
AR-3210-0026
AR-3210-0028
AR-3210-0029
AR-3210-0030
AR-3210-0031
AR-3210-0032
The Arthrex Synergy
UHD4
System Camera Control Unit and
Camera Head User’s Guide provides important information
for the safe operation of all components of the Synergy
UHD4
Camera System, including accessories. Read this User’s
Guide thoroughly prior to using this system and keep it in
an easily accessible place for use by all operating
personnel. Read and follow all safety warnings, cautions
and precautions.
Arthrex, Inc.
1370 Creekside Blvd.
Naples, FL 34108, USA
+1 (800) 934-4404
Technical Support
1-(800) 391-8599
EC REP
Arthrex GmbH
Erwin-Hielscher-Strasse 9
81249 München, Germany
+49 89 909005-0

Table of Contents

Questions and Answers

  • A
    allenalexandraAug 14, 2025
    What to do if there is no video image on the Arthrex Control Unit monitor?
    • N
      nathan94Aug 14, 2025
      If there's no video image on the monitor, ensure the Control Unit and monitor are plugged in and powered on. Confirm all cable connections are correct, rerouting video cables if needed, and check for any cable damage, replacing them if necessary. Also, ensure the camera head cable connector is fully inserted into the Control Unit's camera head receptacle. If the issue persists, try replacing the camera head with a working one to see if the original camera head or cable is faulty and needs repair.
  • T
    troy97Aug 17, 2025
    How to fix intermittent picture on Arthrex AR-3200-0023?
    • D
      David ChavezAug 17, 2025
      To fix an intermittent picture, first, reinsert the camera head connector card edge fully into the CCU camera receptacle. Flex the video and power cables; if the picture is affected, inspect and replace the cables as needed. If flexing the camera cable affects the picture, it may need factory repair or replacement.
  • J
    James CoxAug 21, 2025
    What to do if Arthrex AR-3200-0023 camera does not power up?
    • J
      jennaadamsAug 21, 2025
      If the camera doesn't power up and the standby LED doesn't illuminate, ensure the power cord is plugged into both the CCU and a properly grounded receptacle. If it is, try replacing the power cord, as it may be faulty.
  • H
    Holly GreenAug 25, 2025
    Why Arthrex Control Unit camera will not white balance?
    • M
      Michael SmallAug 25, 2025
      If the monitor indicates “White Balance Fail”, it could be due to too much light, too little light, or the wrong color temperature light. Try moving the scope further away or closer to the white gauze during white balance, or adjust the LED Light Engine brightness accordingly.
  • B
    Beth CastanedaAug 27, 2025
    What to do if Arthrex AR-3200-0023 Control Unit tablet continually restarts?
    • R
      Robin TurnerAug 27, 2025
      If the tablet continually restarts or won't progress beyond the Samsung startup screen, first, check the tablet cable and connector for any damage. Also, ensure you're using a Samsung model EP-TA10JWE charger with a minimum of 2.0A charge current and a USB 3.0 charger cable (both connectors) no longer than 6 ft. (1.83 meters). Replace the charger or cable if they don't meet these specifications.
  • J
    jennifer92Aug 30, 2025
    How to fix poor color reproduction on Arthrex Control Unit?
    • R
      Robyn JonesAug 30, 2025
      To correct poor color reproduction, white balance the camera head.
  • J
    Justin PhillipsSep 3, 2025
    How to fix Arthrex AR-3200-0023 Control Unit system that does not boot up correctly?
    • M
      Miranda ShawSep 3, 2025
      If the system doesn't boot up correctly or banners don't display properly, power down the device, wait three minutes, and then restart the system.
  • J
    Jared HamiltonSep 6, 2025
    Why Arthrex AR-3200-0023 camera head buttons do not function?
    • D
      Dr. Jacob Barnett MDSep 6, 2025
      If the camera head buttons do not function as programmed, reprogram the camera head buttons. Note that this solution applies only to the Tablet Data Input device option.
  • M
    michael33Sep 10, 2025
    What to do if AR-3200-1013 Tablet will not connect to Arthrex CCU?
    • T
      Thomas BellSep 10, 2025
      If the AR-3200-1013 Tablet will not connect to the CCU, update the SynergyUHD4 Software to v4.13.1 or newer.

Summary

Introduction to SynergyUHD4

SynergyUHD4 Intended Use and Contraindications

Defines the system's purpose and lists conditions where the device should not be used.

SynergyUHD4 Warnings and Precautions

Details critical safety information, warnings, cautions, and necessary precautions for operation.

SynergyUHD4 System Installation and Operation

SynergyUHD4 Installation

Step-by-step guide for installing the SynergyUHD4 Camera Control Unit and accessories.

SynergyUHD4 System Setup Facility and Surgeon Settings

Details how to configure facility and surgeon-specific settings via the tablet interface.

SynergyUHD4 Scheduling and Starting Cases

SynergyUHD4 Operation without Tablet Data Input Device

SynergyUHD4 Maintenance

SynergyUHD4 Periodic Maintenance

SynergyUHD4 Cleaning and Sterilizing

Detailed procedures for cleaning and sterilizing the LED Light Engine, CCU, and camera head.

SynergyUHD4 Troubleshooting and Error Resolution

Provides guidance on diagnosing and resolving common system issues and error messages.

SynergyUHD4 Recommended Annual CCU Maintenance

Arthrex AR-3200-0023 Specifications

General IconGeneral
BrandArthrex
ModelAR-3200-0023
CategoryControl Unit
LanguageEnglish
