Arthrex DualWave Quick Reference

5
OUTFLOW TUBING SET-UP
Pass off Cassette and Red Waste Tubing
Shaver
Cut as needed Outow Boot
Waste
Luer Lock
Cannula
Close outow door Outow display Connect red waste
tubing to waste system
Connect to
shaver suction
Connect to
independent cannula
Open outow door
*Install outow cassette
*For easy set-up, move the rollers so that two wheels are ush. Extend the boot of the outow cassette over the two wheels at the
same time. With one hand, hold the boot in place; and, with the second hand, pull down on all three tubes, pushing the cassette
in place. The cassette will be held in place by the edges of the outow bezel.
OUTFLOW
1 2
3 4 5
6
7
