8 Aruba Instant On AP12 Access Point | Installation Guide
Figure 9 Attaching the Mount Bracket to a Solid Surface
2. Attach the AP to the secured mount bracket as shown in Figure 10.
a. Align the AP with the mount bracket, placing the AP so that it’s mounting tabs are at an angle of
approximately 30 degrees to the mount bracket.
3. Pushing towards the solid surface, rotate the AP clockwise until it clicks into place (see Figure 10).
Figure 10 Attaching the AP to the Mount Bracket
AP-to-Bracket Option
1. Place the mount bracket against the back of the AP with the bracket at an angle of approximately 30 degrees
to the tab (see Figure 11).
This mounting option works only with a wall.

Aruba Instant On AP12 Specifications

General

Brand	Aruba
Model	Instant On AP12
Category	Wireless Access Point
Language	English
