3
Installing a FriendlyNet 10T
To install the FriendlyNet 10T Adapter:
1
Locate the AAUI connector on the system you’re connecting
to the Ethernet.
2
Plug the AAUI connector on the adapter’s cable end into the
AAUI connector on the system.
3
Plug the UTP (Unshielded Twisted Pair) Ethernet cable into
the RJ-45 connector on the FriendlyNet 10T Adapter. See
Figure 1.
Figure 1
FriendlyNet 10T Adapter
Macintosh
RJ-45 connector
FriendlyNet cabl
e
AUI conn
F
RIENDLY
N
ET
T M
Macintosh
UTP Ethernet cable
RJ-45 connector
AAUI connector
(14-pin)
friendlynet BOOK Page 3 Thursday, October 16, 1997 10:37 AM
