TD 92579EN
15 February 2012 / Ver. H
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
4
Power Distribution
The IPBS1 can be powered using the following methods:
• Power over Ethernet, IEEE 802.3af
• A local AC-adapter
Note: For
more information about power distribution, see 5.3 Power the Base Station on
page 34.
Software
The software in the IPBS1 can be updated by downloading new software without
dis
connecting the equipment. The new software is stored in flash memory. See 8.18
Update on page 130 for information.
Connectors
• Two 8-pin RJ45 modular jacks for LAN/PoE and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
Status of LED1 (lower LED) Description
Steady Green Operational
Flashing fast amber Download of firmware in progress.
Steady Amber TFTP mode
Alternating red/green No Ethernet connection
Status of LED2 (upper LED) Description
Not lit IPBS1 operational and no traffic on the IPBS1.
Steady green IPBS1 operational and traffic on the IPBS1.
Flashing slow green Fully occupied with traffic.
Flashing red No air synchronization - searching for air sync
candidates.
Flashing fast red Download of RFP software in progress.
Alternating red/green RFP not initialized.
