IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
154
B.2 BS3x0 and DB1
Figure 4.
Cable
length
(metres)
0.4 mm wire size (∅) 0.5 mm wire size (∅) 0.6 mm wire size (∅)
Without
EPP
With
EPP
Without
EP
P
With
EPP
Without
EPP
With
EPP
0 5.0 5.0 5.0 5.0 5.0 5.0
100 5.2 5.1 5.1 5.1 5.1 5.1
200 5.3 5.2 5.2 5.1 5.1 5.1
300 5.6 5.3 5.3 5.2 5.2 5.1
400 5.8 5.5 5.5 5.3 5.3 5.2
500 6.1 5.6 5.6 5.4 5.4 5.2
600 6.5 5.8 5.8 5.5 5.4 5.3
700 7.1 6.0 6.0 5.6 5.5 5.3
800 8.1 6.2 6.2 5.7 5.6 5.4
900 - 6.5 6.5 5.8 5.7 5.4
1000 - 6.9 6.9 5.9 5.8 5.5
1100 - 7.3 7.3 6.1 5.9 5.6
1200 - 8.1 8.1 6.2 6.1 5.6
1300 - - - 6.4 6.2 5.7
1400 - - - 6.6 6.4 5.8
1500 - - - 6.9 6.6 5.8
Table 2 Power consumption (watts) of base stations and cabling when powered from the IPBL
