Ascon Tecnologic - K Series - ENGINEERING MANUAL - PAG. 19
[105] Pr.t3 - Time of the third soak
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF.
Range: 0.00... 99.59 time units.
[106] Pr.b3 - Wait band of the third soak
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF.
Range: OFF... 9999 engineering units.
Note: For more details see [96] Pr.b1 parameter.
[107] Pr.E3 - Events of the third group
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF.
Range: 00.00... 11.11 where:
0 Event OFF;
1 Event ON.
Note: For more details see [97] Pr.E1 parameter.
[108] Pr.S4 - Set point of the fourth soak
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from
OFF.
Range: From [73] SPLL to [74] SPHL;
oFF Program end.
Note: For more details see [98] Pr.S2 parameter.
[109] Pr.G4 - Gradient of the fourth ramp
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF and
[108] Pr.S4 is different from OFF.
Range: 0.1... 999.9 eng. units per minute;
inF Step transfer.
[110] Pr.t4 - Time of the fourth soak
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF and
[108] Pr.S4 is different from OFF.
Range: 0.00... 99.59 time units.
[111] Pr.b4 - Wait band of the fourth soak
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF and
[108] Pr.S4 is different from OFF.
Range: OFF... 9999 engineering units.
Note: For more details see [96] Pr.b1 parameter.
[112] Pr.E4 - Event of the fourth segment
Available: When [89] Pr.F is different from nonE,
[98] Pr.S2 is different from oFF and
[103] Pr.S3 is different from OFF and
[108] Pr.S4 is different from OFF.
Range: 00.00... 11.11 where:
0 Event OFF;
1 Event ON.
Note: For more details see [97] Pr.E1 parameter.
[113] Pr.St - Program status
Available: When [89] Pr.F is different from nonE.
Range: run Program Run;
HoLd Program Hold;
rES Program reset.
Note: This parameter allows to manage program execution
by a parameter.
]PAn Group - Operator HMI
[114] PAS2 - Level 2 password: Limited access level
Available: Always.
Range: oFF Level 2 not protected by password
(as level 1 = Operator level);
1... 999 Level 2 password.
[115] PAS3 - Level 3 password: configuration level
Available: Always.
Range: 3... 999 Level 3 password.
Note: Setting [114] PAS2 equal to [115] PAS3, the level 2
will be masked.
[116] uSrb - button function during RUN TIME
Available: Always.
Range: nonE No function;
tunE Auto-tune/self-tune enabling. A single press
(longer than 1 second) starts the auto-tune.
oPLo Manual mode. The first pressure puts the
instrument in manual mode (oPLo) while the
second one puts the instrument in Auto mode.
AAc Alarm reset.
ASi Alarm acknowledge.
chSP Sequential set point selection
(see note below).
St.by Stand by mode. The first press puts the in-
strument in stand by mode while the second
one puts the instrument in Auto mode .
Str.t Timer run/hold/reset (see note below).
P.run Program run (see note below).
P.rES Program reset (see note below).
P.r.H.r Program run/hold/reset (see note below).
Notes: 1. When “Sequential set point selection” is used, each
pression of button (longer than 1 s) increases
the value of SPAT (active set point) of one step.
The selection is cyclic -> SP1 -> SP2 -> SP3 -> SP4.
When a new set point is selected using the
key, the display shows for 2 s the acronym of the
new set point (e.g. SP2).
2. When “Sequential set point selection” is used, the
no. of set points selectable is limited by [69] nSP.
3. When “Timer run/hold/reset” is selected, a short
press starts/stops(Hold) timer count while a long
press (longer than 10 s) resets the timer.
4. When “Program run” is selected, the first press
starts the program execution but a second press
restarts the program execution from the beginning.
5. When “Program reset” is selected, a short press
resets the program execution.
6. When “Program run/hold/reset” is selected, a short
press starts/stops (Hold) program execution while
a long press (longer than 10 s) resets the program.
