Ascon Tecnologic - KM3 - L - ENGINEERING MANUAL - PAG. 15
Appendix A
]
inP group - Main and auxiliary input confi guration
no. Param. Description
Dec.
Point
Values Default
1 SEnS Sensor selection 0
J = TC J,
crAL = TC K,
S = TC S,
r = TC R,
t = TC T,
n = TC N,
Pt1 = RTD Pt100,
Pt10 = RTD Pt1000,
0.60 = 0 to 60 mV,
12.60 = 12 to 60 mV,
0.20 = 0 to 20 mA,
4.20 = 4 to 20 mA,
0.5 = 0 to 5 V,
1.5 = 1 to 5 V,
0.10 = 0 to 10 V,
2.10 = 2 to 10 V
J
2 dp
Decimal Point Position (linear inputs)
0
0 to 3
1
Decimal Point Position (different than linear inputs)
0/1
3 SSC Initial scale read-out for linear inputs dp -1999 to 9999 0.0
4 FSc Full Scale Readout for linear inputs dp -1999 to 9999 999.9
5 unit Engineer unit °C/°F °C
6 FiL Digital filter on the measured value 1 0 (= OFF) to 20.0 s 1.0
7 bS PV input bias -100 to 100 % of the input spen 0
8 diA -100 to 100 % of the input spen
0 = DI1 direct,
1 = DI1 reverse
0
]
out group
no. Param. Description
Dec.
Point
Values Default
9 o1t
Output 1 type
(when Out 1 is an analog output)
0-20 = 0 to 20 mA;
4-20 = 4 to 20 mA;
0-10 = 0 to 10 V;
2-10 = 2 to 10 V.
4-20
10 o1F
Out 1 function
0
nonE = Output not used;
r.inP = Measure retransmission;
r.Err = Error (PV - SP) retransmission;
r.SP = Set point retransmission ;
r.SEr = Serial value retransmission.
r.inP
11 Ao1L
Initial scale value of the analog retransmission
dP -1999 ... Ao1H -199.9
12 Ao1H Full scale value of the analog retransmission dP Ao1L ... 9999. 999.9
13 o3F Out 3 function 0
NonE = Output not used
AL = Alarm output
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF =
Out-of-range, burn out and Power failure indicator
AL
14 o3AL Alarms linked up with the out 3 0
0 to 15
+1 = Alarm 1
+2 = Alarm 2
+4 = Sensor Break
+8 = Overload on output 4
1
15 o3Ac Out 3 action 0
dir = Direct action
rEU = Reverse action
dir
16 o4F Out 4 function 0
NonE = Output not used
AL = Alarm output
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF =
Out-of-range, burn out and Power failure indicator
on = Output ever ON (osed as auxiliary PWS for a
transmitter)
AL
17 o4AL Alarms linked up with the out 4 0
0 to 15
+1 = Alarm 1
+2 = Alarm 2
+4 = Sensor Break
+8 = Overload on output 4
2
