Ascon Tecnologic - KM3 - L - ENGINEERING MANUAL - PAG. 16
no. Param. Description
Dec.
Point
Values Default
18 o4Ac Out 4 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
dir
]
AL1 group
no. Param. Description
Dec.
Point
Values Default
19 AL1t Alarm 1 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAo = Windows alarm in alarm outside the windows
LHAI = Windows alarm in alarm inside the windows
SE.br = Sensor Break
LodE = Deviation low alarm (relative)
HidE = Deviation high alarm (relative)
LHdo = Relative band alarm in alarm out of the band
LHdi = Relative band alarm in alarm inside the band
HiAb
20 Ab1 Alarm 1 function 0
0 to 3
+1 = Not active at power up
+2 =
Relative alarm not active at set point change
0
21 AL1L
- For High and low alarms, it is the low limit
of the AL1 threshold;
- For band alarm, it is low alarm threshold
dp From -1999 to AL1H (E.U.) -199.9
22 AL1H
- For High and low alarms, it is the high
limit of the AL1 threshold;
- For band alarm, it is high alarm threshold
dp From AL1L to 9999 (E.U.) 999.9
23 AL1 AL1 threshold dp From AL1L to AL1H (E.U.) 0.0
24 HAL1 AL1 hysteresis dp 1 to 9999 (E.U.) 0.1
25 AL1d AL1 delay 0 From 0 (oFF) to 9999 (s) oFF
]
AL2 group
no. Param. Description
Dec.
Point
Values Default
26 AL2t Alarm 2 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAo = Windows alarm in alarm outside the windows
LHAI = Windows alarm in alarm inside the windows
SE.br = Sensor Break
LodE = Deviation low alarm (relative)
HidE = Deviation high alarm (relative)
LHdo = Relative band alarm in alarm out of the band
LHdi = Relative band alarm in alarm inside the band
LoAb
27 Ab2 Alarm 2 function 0
0 to 3
+1 = Not active at power up
+3 =
Relative alarm not active at set point change
0
28 AL2L
- For High and low alarms, it is the low limit
of the AL2 threshold;
- For band alarm, it is low alarm threshold
dp From -1999 to AL2H (E.U.) -199.9
29 AL2H
- For High and low alarms, it is the high
limit of the AL2 threshold;
- For band alarm, it is high alarm threshold
dp From AL2L to 9999 (E.U.) 999.9
30 AL2 AL2 threshold dp From AL2L to AL2H (E.U.) 0.0
31 HAL2 AL2 hysteresis dp 1 to 9999 (E.U.) 0.1
32 AL2d AL2 delay 0 From 0 (oFF) to 9999 (s) oFF
