Ascon Tecnologic - KM3 - L - ENGINEERING MANUAL - PAG. 17
]
rEG group - Control Parameters
no. Param. Description
Dec.
Point
Values Default
33 HI.Lo Limit Control type 0
HI = High limit
Lo = Low limit
Hi
34 r.nd Restart mode 0
0 = limit output is ON in any case (the instruemnt start in shout-
down condition)
1 = limit output is OFF when, at power on, PV doesn’t exceed SP.
0
35 HYS Hysteresis of the control output dP from 0.0 to 100 % of the input spen in E.U. 5%
36 oP.SL Operative display selection
0 = PV and SP / SP only (lower display)
1 = SP only (lower display)
0
37 SPLL Minimum set point value dP From -1999 to SPHL -199.9
38 SPHL Maximum set point value dP From SPLL to 9999 999.9
39 SP Set point dP From SPLL to SPLH 0.0
40 diS The way to confirming operation 0
but = by keyboard
dI = by digital input
but
41 tim
Duration time of the last exceeded
periode (in shoutdown)
2 HH.mm
42 Hi Mximum measured value dP E.U.
43 Lo Mininum masured value dP E.U.
]
PAn group - Operator HMI parameters
no. Param. Description
Dec.
Point
Values Default
44 PAS2
Level 2 password (limited
access level)
0
- oFF (Level 2 not protected by password);
- 1 to 200.
20
45 PAS3
Level 3 password (com-
plete configuration level)
0 3 to 200 30
46 di.cL Display colour
0 =
The display colour is used to show the exceeded condition
1 = Display red (fix);
2 = Display green (fix);
3 = Display orange (fix).
0
47 diS.t Display Timeout 2
- oFF (display always ON);
- 0.1 to 99.59 (mm.ss).
oFF
]
Ser group - Serial link parameters
no. Param. Description
Dec.
Point
Values Default
48 Add Instrument address
- oFF
- 1 to 254
1
49 bAud baud rate
1200 = 1200 baud
2400 = 2400 baud
9600 = 9600 baud
19.2 = 19200 baud
38.4 = 38400 baud
9600
]
cAL group - User calibration parameters
no. Param. Description
Dec.
Point
Values Default
50 A.L.P Adjust Low Point dP From -1999 to (AH.P - 10) in engineering units 0.0
51 A.L.o Adjust Low Offset dP -300 to +300 (E.U.) 0.0
52 A.H.P Adjust High Point dP From (AL.P + 10) to 9999 engineering units 999.9
53 A.H.o Adjust High Offset dP -300 to +300 0.0
